DEPARTMENT OF MECHANICAL ENGINEERING
Mechanics of Solids Lab
The objectives of mechanics of solids lab is determine the various properties of materials such as stresses against compression, tension, shear and bending, hardness, impact strength, stiffness, young modulus, etc. and select the suitable material for the required purpose.mos lab demonstrating the basic principles of engg mechanics, mechanics of solids and design of machine members to students through a serious of experiments.
Major equipments of mos lab: universal testing machine, torsion testing machine, impact testing machine, Brinell hardness testing machine, rockiness hardness testing machine.
Mr. P.Nagabharam
Laboratory In-Charge
EQUIPMENT AVAILABLE
| S.No. | Name of the Equipments |
|---|---|
| 1 | Universal Testing Machine 20 ton Capacity Model : UTM 1Ba) Shear Test attachment for any of the above Model: SHTA 2Db) Brinell Test attachment for any of the above Model: BA 3Cc) Extensometer for any of the above Model: EXTM |
| 2 | Torison Testing Machine 50kg Capacity Model: AMT 3D |
| 3 | Rockwell Hardness Tester Model: RKWHT |
| 4 | Impact Tester for Izod & Charpy Tests Model: MAT 8 |
| 5 | Deflection Testing Apparatus on simple beam Model: DTAB 22 |
| 6 | Spring Testing Machine Model: STM 300 |
| 7 | Bench vice 4inch |
| 8 | Triangular Files 10 inches |
| 9 | Flat Files 12 Inches |
| 10 | Hacksaw Frames |
| 11 | Universal Testing Machine UTM-40 |
